REDCRAFT is an open-source software tool for determining a protein's structure using residual dipolar couplings (RDCs). It allows simultaneous determination of a protein's structure and dynamics. Its effectiveness has been demonstrated on both synthetic and experimental data. REDCRAFT contains stages that allow the incorporation of user-specified dihedral angle constraints, such as those produced by TALOS or a restriction to specific regions of Ramachandran space. It is robust with respect to noise and missing data. The program is highly efficient and can produce a structure for an 80-residue protein within two hours.
Bryson, Michael, Fang Tian, James H. Prestegard, and Homayoun Valafar. "REDCRAFT: A tool for simultaneous characterization of protein backbone structure and motion from RDC data." Journal of Magnetic Resonance 191.2 (2008): 322-34.
REDCAT is a software package for the analysis of residual dipolar couplings (RDCs) for structure validation and elucidation. In addition to basic utilities to solve for order tensors and back-calculate couplings from a given order tensor and proposed structure, a number of improved algorithms have been incorporated. These include the proper sampling of the Null-space (when the system of linear equations is under-determined), more sophisticated filters for invalid order-tensor identification, error analysis for the identification of the problematic measurements, and simulation of the effects of dynamic averaging processes. REDCAT is a user-friendly program with excellent performance. The modular implementation of REDCAT's algorithms, with separation of the computational engine from the graphical engine, allows for flexible and easy command line interaction.
Valafar, Homayoun, and James H. Prestegard. "REDCAT: a residual dipolar coupling analysis tool." Journal of Magnetic Resonance 167.2 (2004): 228-41.
Probability Density Profile Analysis (PDPA) is a tool that uses multiple correlated unassigned RDC data sets and an estimation of experimental error to produce a probabilityu density function for the true distribution of RDC's. This is used as a structural fingerprint which is then compared to simulated RDC data freom a library of structures to determine the best match. Applications include novel protein fold target selection for structural genomics initatives, structural homologue detection for structure determintation by threading, and confirmation of computationally modeled protein structures from a small amount of experimental data.
Bansal, Sonal, Xijiang Miao, Michael W. Adms, James H. Prestegard, and Homayoun Valafar. "Rapid Classification of protein structure models using unassigned backbone RDCs and probability density profile analysis (PDPA)." Journal of Magnetic Resonance 192.1 (2008): 60-68.
While many distance metrics, for instance backbone RMSD, exist to quantify the difference between protein structures, none exist that are based on the protein's torsion angles. TALI defines each protein as a sequence of triples consisting of 2 torsion angles and a residue type. Drawing on idea behind local and global sequence alignment tools such as the Needleman-Wunsch algorithm, TALI computes a distance metric that is sensitive to similarity in local structure, and is insensitive to small localized changes in structure that can have a huge impact on backbone RMSD. Applications include domain detection, structural homology detection, and phylogeny reconstruction. For more information, see Tali: Protein Structure Alignment Using Backbone Torsion Angles, and Tali: local alignment of protein structures using backbone torsion angles.
Initial Publication: Reference Here
Multiple structure alignments have received considerable attention as an alternative to multiple sequence alignments. msTALI is a multiple structure alignment algorithm that utilizes several types of information, including torsion angles, backbone atom positions, surface accessibility, residue type, and others. It combines this information into an efficient progressive alignment algorithm. Applications include protein core extraction, active site identification, and many others. msTALI allows the user to specify the extent to which each type of information is used, and this allows the algorithm to be applicable to a wide variety of problems.
Initial Publication: Paul Shealy and Homayoun Valafar: An Investigation in Aligning Multiple Protein Structures Using Biochemical and Biophysical Properties. BIOCOMP 2009: 10-16
Protein structure phylogeny...
Initial Publication: Reference Here
Given the increasing availability of RDC data sets collected in 2 alignment media, there is a need for accurate order tensor estimation techinques that leverage the correlation between the data collected in each alignment. approx2D is a web application and associated C++ engine that extracts both the principal order parameters and the relative orientation of the principal alignment frames of the two alignment media without the need for assignment or structure. The web application is a hosted version of the approx2D utility with an easy to use interface and workflow. For automated runs or for interfacing directly with other C++ code, the C++ engine is also available as a standalone download.
Advances in NMR instrumentation and pulse sequence design have resulted in easier acquisition of Residual Dipolar Coupling (RDC) data. However, computational and theoretical analysis of this type of data has continued to challenge the international community of investigators because of their complexity and rich information content. Contemporary use of RDC data has required a-priori assignment, which significantly increases the overall cost of structural analysis. This article introduces a novel algorithm that utilizes unassigned RDC data acquired from multiple alignment media (nD-RDC, n greater-or-equal, slanted 3) for simultaneous extraction of the relative order tensor matrices and reconstruction of the interacting vectors in space.
Estimation of the relative order tensors and reconstruction of the interacting vectors can be invaluable in a number of endeavors. An example application has been presented where the reconstructed vectors have been used to quantify the fitness of a template protein structure to the unknown protein structure. This work has other important direct applications such as verification of the novelty of an unknown protein and validation of the accuracy of an available protein structure model in drug design. More importantly, the presented work has the potential to bridge the gap between experimental and computational methods of structure determination.
Xijiang Miao, Rishi Mukhopadhyay, Homayoun Valafar, "Estimation of relative order tensors, and reconstruction of vectors in space using unassigned RDC data and its application." Journal of Magnetic Resonance, 194.2 (2008): 202-211
SCOPE (Semi Classical Open Source Protein Energy) is an open-source program that has been implemented in the Object Oriented C++ language, capable of computing none-bonded energies for protein structures from first principles. SCOPE is also capable of manipulating protein structures within the Rotamer space instead of the typical Cartesian space. This approach simplifies calculation of the transitional force field through elimination of unnecessary terms such as bond lengths, bond angles, and other peptide geometrical constraints. Elimination of unnecessary force calculation is beneficial in improving computational performance while the OO approach results in better program maintenance and customization for other projects. Finally, the calculation of forces has been compared and confirmed with respect to other commonly used programs such as CHARMM and Xplor-NIH. Further development of SCOPE can be very beneficial in refinement of computationally modeled structures, or potentially Ab-Initio calculation of structures from first principles without any reliance on homology modeling.
Initial Publication: Reference Here
